Revolt X Advanced Pro 0 (2024) | bike

7,449.00

Features:

Clear
SKU: N/A Categories: , ,

Additional information

Colour

Size

, , , ,

Specifications

Washboard descents, sketchy dirt, gravel and rocks of all shapes and sizes. You never know what you’ll get on a gravel ride. This composite gravel machine has front suspension and engineered compliance to help you float through it all with speed and control.

Key Performance Factors

Smooth control

Composite frameset is designed specifically for front suspension. With 40mm of travel, the fork absorbs impacts so you can ride smoother and faster on rugged gravel and dirt.

Tuned compliance

Lowered seatstays with smaller diameter tubes absorb road shocks and vibrations. A Contact SL XR D-Fuse handlebar adds more compliance without sacrificing the stiffness needed for cornering, sprinting or climbing.

Adaptable to the terrain

A flip chip on the rear dropout adjusts the wheelbase short for quicker handling, or long for improved stability at speed. The long setting also allows for larger diameter tires up to 53mm. You can choose the included dropper/suspension seatpost for added

Sizes S, M, M/L, L, XL
Colours Gloss Kelp Forest/Charcoal/Chrome
Frame Advanced-grade composite, 12x142mm thru-axle, disc, flip chip dropout
Fork Fox 32 Float AX Performance Elite, 40mm, Fit 4 damper12x100mm thru-axle
Shock N/A
Handlebar Giant Contact SL XR D-Fuse, 31.8mm S:44cm, M:46cm, M/L:46cm, L:48cm, XL:48cm
Grips Stratus Lite 3.0
Stem Giant Contact, 8-degree S:50mm, M:60mm, M/L:70mm, L:70mm, XL:80mm
Seatpost Post Moderne, dropper, 30.9mm with 30mm of suspension S:415mm / 100mm drop M:415mm / 100mm drop M/L: 415mm / 100mm drop L:415mm / 100mm drop XL: 415mm / 100mm drop
Saddle Giant Approach SL
Pedals PEDALS NOT SUPPLIED
Shifters SRAM Force eTap AXS, 1×12
Front Derailleur N/A
Rear Derailleur SRAM X01 Eagle AXS
Brakes SRAM Force eTap AXS hydraulic, SRAM CenterLine rotors [F]160mm, [R]160mm
Brake Levers SRAM Force eTap AXS hydraulic
Cassette SRAM XG-1295, 12-speed, 10×52
Chain SRAM X01 Eagle
Crankset SRAM Force D1 DUB, 40t S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket SRAM DUB, press fit
Rims Giant CXR 1 X1 Carbon Disc WheelSystem, [F] 25.8mm, [R] 25.8mm
Hubs [F] Giant CXR X alloy, CenterLock, 12mm thru-axle, [R] Giant CXR X alloy, 60t ratchet driver, CenterLock, 12mm thru-axle
Spokes Sapim Laser
Tyres Maxxis Rambler, 700x50c, tubeless
Extras Factory tubeless set up, 53mm max tyre size in “long” flip chip position, 45mm max tyre size in “short” flip chip position
Max Chainring Size SRAM Wide 1x 44T. Shimano GRX 1x 42T

Geometry

    ML XL M L S
A SEAT TUBE LENGTH 490 530 470 510 450
B SEAT TUBE ANGLE 73 73 73.5 73 73.5
C TOP TUBE LENGTH 575 600 560 585 553
D HEAD TUBE LENGTH 130 160 115 145 100
E HEAD TUBE ANGLE 72 72 71.5 72 71
F FORK RAKE 50 50 50 50 50
G TRAIL 70.1 70.1 73.5 70.1 76.9
H WHEEL BASE 1031 1057 1026 1041 1024
I CHAIN STAY LENGTH 425 425 425 425 425
J BOTTOM BRACKET DROP 68 68 68 68 68
K STACK 592 621 576 607 560
L REACH 393 410 389 399 387
M STAND OVER HEIGHT 772 808 755 790 736
N HANDLERBAR WIDTH 460 480 460 480 440
O STEM LENGTH 80 90 70 80 60
P CRANK LENGTH DEC 172.5 175 172.5 175 170
Q WHEEL SIZE ALT 700x 42C | 700x 42C | 700x 42C | 700x 42C | 700x 42C |
