Here’s to long rides. Climb higher mountains, skip the shortcuts. This buttery smooth endurance road bike helps you do more of what you love.
Here’s to long rides. Climb higher mountains, skip the shortcuts. This buttery smooth endurance road bike helps you do more of what you love.
Here’s to long rides. Climb higher mountains, skip the shortcuts. This buttery smooth endurance road bike helps you do more of what you love.
Here’s to long rides. Climb higher mountains, skip the shortcuts. This buttery smooth endurance road bike helps you do more of what you love.
| Sizes | XS, S, M, M/L, L, XL |
|---|---|
| Colours | Stealth Chrome |
| Frame | Advanced-grade Composite, 12x142mm thru-axle, disc |
| Fork | Advanced SL-grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc |
| Handlebar | Giant Contact SL D-Fuse XS:404/380mm, S:404/380mm, M:424/400mm, M/L:424/400mm, L:444/420mm, XL:444/420mm |
| Grips | Stratus Lite 3.0 |
| Stem | Giant Contact SL AeroLight XS:80mm, S:90mm, M:100mm, M/L:100mm, L:110mm, XL:110mm |
| Seatpost | Giant D-Fuse SL, composite, -5/+15mm offset |
| Saddle | Giant Fleet SL |
| Shifters | Shimano 105 |
| Front Derailleur | Shimano 105 |
| Rear Derailleur | Shimano 105 |
| Brakes | Shimano 105 hydraulic, Shimano RT-CL700 rotors [F]160mm, [R]160mm |
| Brake Levers | Shimano 105 hydraulic |
| Cassette | Shimano 105, 12-speed, 11×36 |
| Chain | KMC X12L-1 |
| Crankset | Shimano 105, 34/50 XS:165mm, S:165mm, M:170mm, M/L:170mm, L:172.5mm, XL:172.5mm |
| Bottom Bracket | Shimano, press fit |
| Rims | Giant SLR 2 40 Carbon Disc WheelSystem |
| Hubs | [F] Giant Low Friction Hub, CenterLock, 12mm thru-axle, [R] Giant Low Friction Hub, 30T ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | Sapim |
| Tyres | Giant Gavia Fondo 0, tubeless, 700x32c (33.5mm), folding |
| Extras | computer mount, fender mount, water bottle cages, tubeless prepared, 40mm max tire size |

| XXS | XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 445 | 480 | 515 | 535 | 565 | ||
| B | SEAT TUBE ANGLE | 74 | 73.5 | 73 | 73 | 73 | ||
| C | TOP TUBE LENGTH | 530 | 545 | 560 | 575 | 595 | ||
| D | HEAD TUBE LENGTH | 135 | 150 | 175 | 195 | 215 | ||
| E | HEAD TUBE ANGLE | 71.8 | 72.5 | 72.5 | 72.5 | 72.5 | ||
| F | FORK RAKE | 50 | 50 | 50 | 50 | 50 | ||
| G | TRAIL | 63.4 | 58.6 | 58.6 | 58.6 | 58.6 | ||
| H | WHEEL BASE | 994 | 998 | 1,010 | 1,025 | 1,040 | ||
| I | CHAIN STAY LENGTH | 420 | 420 | 420 | 420 | 420 | ||
| J | BOTTOM BRACKET DROP | 75 | 75 | 70 | 70 | 70 | ||
| K | STACK | 541 | 558 | 577 | 596 | 615 | ||
| L | REACH | 375 | 380 | 384 | 393 | 402 | ||
| M | STAND OVER HEIGHT | 733 | 762 | 796 | 814 | 841 | ||
| N | HANDLEBAR WIDTH | 404 | 424 | 424 | 444 | 444 | ||
| O | STEM LENGTH | 90 | 100 | 100 | 110 | 110 | ||
| P | CRANK LENGTH DEC | 165 | 170 | 170 | 172.5 | 172.5 | ||
| Q | WHEEL SIZE ALT |
