Go long. Go fast. Superlight and silky smooth, the flagship series of the new Defy range is back to reclaim its title as the pinnacle of endurance road. It’s the perfect choice for the sportive or gran fondo that’s circled on your calendar.
Defy Advanced SL 1
Go long. Go fast. Superlight and silky smooth, the flagship series of the new Defy range is back to reclaim its title as the pinnacle of endurance road. It’s the perfect choice for the sportive or gran fondo that’s circled on your calendar.
Specifications
Go long. Go fast. Superlight and silky smooth, the flagship series of the new Defy range is back to reclaim its title as the pinnacle of endurance road. It’s the perfect choice for the sportive or gran fondo that’s circled on your calendar.
Key Performance Factors
Functional simplicity
Free of cumbersome gimmickry, the frameset is one of the lightest in its category. With a perfect balance of high-performance reactivity and all-day comfort, it offers a “less is more” experience for modern endurance road riding.
Free of cumbersome gimmickry, the frameset is one of the lightest in its category. With a perfect balance of high-performance reactivity and all-day comfort, it offers a “less is more” experience for modern endurance road riding.
Engineered compliance
Advanced SL-grade composite frame and fork are specifically engineered for endurance road riding, delivering a smooth and efficient ride quality that minimizes fatigue on long rides. The new D-Fuse components work together to further absorb road shocks and vibrations.
Advanced SL-grade composite frame and fork are specifically engineered for endurance road riding, delivering a smooth and efficient ride quality that minimizes fatigue on long rides. The new D-Fuse components work together to further absorb road shocks and vibrations.
Total control
A new Contact D-Fuse handlebar features ergonomic shaping and an 8-degree flare for comfort and control on all-day rides. Wide, hookless carbon rims (22.4mm inner width) are optimized for high-volume tubeless tires (up to 38mm), and a 40mm rim depth offers stable, predictable handling in crosswinds.
A new Contact D-Fuse handlebar features ergonomic shaping and an 8-degree flare for comfort and control on all-day rides. Wide, hookless carbon rims (22.4mm inner width) are optimized for high-volume tubeless tires (up to 38mm), and a 40mm rim depth offers stable, predictable handling in crosswinds.
| Sizes | XS, S, M, M/L, L, XL |
|---|---|
| Colours | Dark Green |
| Frame | Advanced SL-grade Composite, 12x142mm thru-axle, integrated seatpost, disc |
| Fork | Advanced SL-grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc |
| Shock | N/A |
| Handlebar | Giant Contact SLR D-Fuse XS:404/380mm, S:404/380mm, M:424/400mm, M/L:424/400mm, L:444/420mm, XL:444/420mm |
| Grips | Stratus Lite 3.0 |
| Stem | Giant Contact SLR AeroLight XS:80mm, S:90mm, M:100mm, M/L:100mm, L:110mm, XL:110mm |
| Seatpost | Giant D-Fuse SLR, composite, -5/+15mm offset |
| Saddle | Giant Fleet SLR |
| Pedals | platform pedal [GCS,GTS], N/A [all other GSC] |
| Shifters | SRAM Force AXS E1 |
| Front Derailleur | SRAM Force AXS E1 |
| Rear Derailleur | SRAM Force AXS E1 |
| Brakes | SRAM Force E1 hydraulic, SRAM PaceLine X rotors [F]160mm, [R]160mm |
| Brake Levers | SRAM Force AXS E1 |
| Cassette | SRAM Force E1, 12-speed, 10×36 |
| Chain | SRAM Force E1 |
| Crankset | SRAM Force E1 DUB, 33/46 with power meter XS:165mm, S:165mm, M:170mm, M/L:170mm, L:172.5mm, XL:172.5mm |
| Bottom Bracket | SRAM, press fit |
| Rims | Giant SLR 0 40 Carbon Disc WheelSystem |
| Hubs | [F] Giant Low Friction Hub, CenterLock, 12mm thru-axle [R] Giant Low Friction Hub, 40T ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | Sapim |
| Tyres | CADEX Classics, tubeless, 700x32c (33.5mm), folding |
| Extras | computer mount, fender mount, water bottle cages, tubeless prepared, 40mm max tire size |
| Max Tire Clearance | 40mm |
Highlights
Barcode : 4711291207196
Geometry
| XXS | XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 445 | 480 | 515 | 535 | |||
| B | SEAT TUBE ANGLE | 74 | 73.5 | 73 | 73 | |||
| C | TOP TUBE LENGTH | 530 | 545 | 560 | 575 | |||
| D | HEAD TUBE LENGTH | 135 | 150 | 175 | 195 | |||
| E | HEAD TUBE ANGLE | 71.8 | 72.5 | 72.5 | 72.5 | |||
| F | FORK RAKE | 50 | 50 | 50 | 50 | |||
| G | TRAIL | 63.4 | 58.6 | 58.6 | 58.6 | |||
| H | WHEEL BASE | 994 | 998 | 1,010 | 1,025 | |||
| I | CHAIN STAY LENGTH | 420 | 420 | 420 | 420 | |||
| J | BOTTOM BRACKET DROP | 75 | 75 | 70 | 70 | |||
| K | STACK | 541 | 558 | 577 | 596 | |||
| L | REACH | 375 | 380 | 384 | 393 | |||
| M | STAND OVER HEIGHT | 733 | 762 | 796 | 814 | |||
| N | HANDLEBAR WIDTH | 404 | 424 | 424 | 444 | |||
| O | STEM LENGTH | 90 | 100 | 100 | 110 | |||
| P | CRANK LENGTH DEC | 165 | 170 | 170 | 172.5 | |||
| Q | WHEEL SIZE ALT |
