Giant
Seek
€23,499.00
RIDE TO WORK QUOTE
Form not Found. Please contact your site administrator.
| Sizes | XS, S, M, M/L, L, XL |
|---|---|
| Colours | Electron Blue |
| Frame | ALUXX-grade aluminum, 12x142mm thru-axle, disc |
| Fork | Advanced-grade composite, composite OverDrive steerer, 12x100mm thru-axle, disc |
| Shock | N/A |
| Handlebar | Giant Sport Flat, 31.8 XS:64cm, S:64cm, M:68cm, M/L: 68cm, L:68cm, XL:68cm |
| Grips | Giant ErgoContact |
| Stem | Giant Contact, 8-degree XS:70mm, S:80mm, M:90mm, M/, L:100mm, XL:110mm |
| Seatpost | Giant D-Fuse, alloy, 350mm |
| Saddle | Giant ErgoContact |
| Pedals | platform pedal |
| Shifters | Shimano CUES U6000, 11-speed |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano CUES |
| Brakes | Tektro HD-R280, Giant MPH rotors [F]160mm, [R]160mm |
| Brake Levers | Tektro HD-R280 |
| Cassette | Shimano CS-LG40011, 11×45 |
| Chain | Shimano CN-LG500 |
| Crankset | FSA Omega AGX+, 42t XS:170mm, S:170mm, M:170mm, M/L:172.5mm, L:172.5mm, XL: 175mm |
| Bottom Bracket | threaded |
| Rims | Giant S-X2 Disc wheelset |
| Hubs | Giant alloy, 12mm thru-axle |
| Spokes | Sapim |
| Tyres | Maxxis Re-Fuse, tubeless, 700x40c |
| Extras | tubeless prepared, 42mm max tire size |
| Max Tire Clearance | 42mm |
| XXS | XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 455 | 475 | 495 | 525 | 555 | ||
| B | SEAT TUBE ANGLE | 73.5 | 73.5 | 73 | 73 | 73 | ||
| C | TOP TUBE LENGTH | 560 | 575 | 590 | 610 | 630 | ||
| D | HEAD TUBE LENGTH | 130 | 155 | 175 | 200 | 225 | ||
| E | HEAD TUBE ANGLE | 70.5 | 71 | 71 | 71.5 | 71.5 | ||
| F | FORK RAKE | 50 | 50 | 50 | 50 | 50 | ||
| G | TRAIL | 73.7 | 70.4 | 70.4 | 67.1 | 67.1 | ||
| H | WHEEL BASE | 1,047 | 1,058 | 1,069 | 1,084 | 1,105 | ||
| I | CHAIN STAY LENGTH | 435 | 435 | 435 | 435 | 435 | ||
| J | BOTTOM BRACKET DROP | 75 | 75 | 75 | 75 | 75 | ||
| K | STACK | 552 | 578 | 597 | 623 | 646 | ||
| L | REACH | 396 | 404 | 407 | 419 | 432 | ||
| M | STAND OVER HEIGHT | 736 | 756 | 773 | 800 | 826 | ||
| N | HANDLEBAR WIDTH | 640 | 680 | 680 | 680 | 680 | ||
| O | STEM LENGTH | 80 | 90 | 90 | 100 | 110 | ||
| P | CRANK LENGTH DEC | 170 | 170 | 172.5 | 172.5 | 172.5 | ||
| Q | WHEEL SIZE ALT | 700C | 700C | 700C | 700C | 700C |
