Reign SX

€5,399.00

Big hits and all-out descents. This trail-crushing enduro machine delivers confidence and control for the rowdiest terrain. Its mixed wheel size, with a 29-inch front and 27.5-inch rear, blends stability and speed with agility that pops.

Additional information

Size	L, M, XL
Color	Moonstone

Specifications

Key Performance Factors

Race-bred suspension
Maestro rear suspension eats up enduro terrain with 165mm of smooth, active rear travel matched with a 190mm travel fork. The trunnion mount rear shock has a longer stroke (65mm over 60mm on the
previous generation) while the Advanced Forged Composite upper rocker arm adds stiffness and lowers overall frame weight.

Adjustable enduro geometry
Flip chip adjustability lets you switch between two settings depending on the terrain. You can select a 63.1 or 63.5-degree head angle and corresponding 77.9 or 78.3-degree seat tube angle, resulting in a 25 or 19mm bottom bracket drop (size medium) to fine-tune handling for varying trail conditions and riding style.

Mixed wheel size
A 29-inch front wheel provides speed, stability and front-end control on rough, technical trails. A 27.5-inch rear wheel adds agility and maneuverability to help riders rail corners, pop over features and show off their style.

Sizes	M, L, XL
Colours	Moonstone
Frame	ALUXX SL-grade aluminum front and rear triangles, 165mm Maestro suspension, flip chip, 12x148mm thru-axle, 27.5-inch rear wheel compatible, flip chip – Maestro 3, integrated down tube storage
Fork	RockShox BoXXer, Charger 3 RC damper, 190mm, 20×110, custom tuned for Giant
Shock	RockShox Vivid Base, lockout, 205/65
Handlebar	Giant Contact SL TR35, 800x35mm, 20mm rise
Grips	Giant Tactal Pro Single
Stem	TruVativ Descendant Direct Mount 35, 50mm
Seatpost	Giant Contact, 30.9mm, 400mm
Saddle	Giant Romero
Pedals
Shifters	microSHIFT Trail Trigger Pro, 1×10
Front Derailleur	N/A
Rear Derailleur	microSHIFT Advent X
Brakes	TRP EVO DH-R, hydraulic, TRP rotors [F]220mm, [R]200mm
Brake Levers	TRP EVO DH-R
Cassette	microSHIFT Advent X, 11-48
Chain	KMC X-10
Crankset	Praxis Cadet HD M24, 32t, 165mm, 55mm chainline
Bottom Bracket	Praxis, press fit
Rims	Giant TRA 2 wheelset, 6061 alloy, hookless, 30mm inner width, 40mm outer width, 21mm height, Wide Guard Technology
Hubs	[F] Giant MTB alloy, six-bolt, [R] Giant MTB alloy, 72 POE (Points of Engagement), six-bolt, HG driver body
Spokes	Sapim, 28, J-bend
Tyres	[F] Maxxis Assegai 29×2.5 WT, 3C MaxxTerra, EXO+, TR [R] Maxxis Assegai 27.5×2.5 WT, 3C MaxxGrip, DD, TR tubeless
Extras	tubeless prepared, 2.5″ max tire size, 36t max chainring size, MRP AMG CS chain guide

Geometry

		M	L	XL
A	SEAT TUBE LENGTH	425	450	475
B	SEAT TUBE ANGLE
C	TOP TUBE LENGTH
D	HEAD TUBE LENGTH	105	115	120
E	HEAD TUBE ANGLE
F	FORK RAKE	56	56	56
G	TRAIL
H	WHEEL BASE
I	CHAIN STAY LENGTH
J	BOTTOM BRACKET DROP
K	STACK
L	REACH
M	STAND OVER HEIGHT
N	HANDLEBAR WIDTH	800	800	800
O	STEM LENGTH	50	50	50
P	CRANK LENGTH DEC	165	165	165
Q	WHEEL SIZE ALT	F 29 \| R 27.5	F 29 \| R 27.5	F 29 \| R 27.5
