TCR Advanced Pro 0 Di2

€7,499.00

Superlight, ultra-efficient and rides like a dream. This well-rounded race bike blends industry-leading composite frame engineering with fully integrated components to help you climb, corner and descend with astonishing speed and sublime road handling.

Category: Bikes, Performance & Racing, Road Bikes Tag: 3247, Apply Now, Giant

View

Size L, M, ML, S, XL, XS

Color Mercury, Ocean Twilight

Specifications

Key Performance Factors

SYSTEM OPTIMIZATION
The frameset, wheels, cockpit and other parts are engineered, developed and tested together to perform as a system. The all-new OverDrive Aero steerer tube technology is combined with a Contact SL AeroLight stem and Contact SL handlebar to incorporate internal cable routing that integrates the top cap, cables and spacers in a more aerodynamic, user-friendly setup.

WINNING EFFICIENCY
Featuring a greater stiffness-to-weight ratio than the previous generation, along with new aero tube shaping and a lighter overall weight, this uncompromising race bike delivers explosive acceleration and unyielding pedaling stiffness. The result is race-winning performance in the moments that count.

INTEGRATED AERODYNAMICS
All tube shapes are engineered and developed using Computational Fluid Dynamics (CFD) modeling and wind-tunnel testing. From the truncated ellipse shape of frameset tubing to a new cockpit design and component integration, it all adds up to a more streamlined profile that improves overall aero performance compared to the previous generation.

Sizes	XS, S, M, ML, L, XL
Colours	Gloss Ocean Twilight/Lightning & Gloss Mercury/Lightning Black
Frame	Advanced-Grade Composite 12x142mm thru-axle, Disc
Fork	Advanced SL-Grade Composite, Full-Composite OverDrive Aero Steerer, 12x100mm thru-axle, Disc
Handlebar	Giant Contact SLR, 10.5 degree flare
Grips	Giant Stratus Lite 2.0 with gel
Stem	Giant Contact SL Aerolight
Seatpost	Giant Variant, composite, -5/+15mm offset
Saddle	Giant Fleet SL 7mm SST Rail With Giant ParticleFlow technology
Pedals	PEDALS NOT SUPPLIED
Shifters	Shimano Ultegra Di2 2×12
Front Derailleur	Shimano Ultegra Di2
Rear Derailleur	Shimano Ultegra Di2
Brakes	Shimano Ultegra hydraulic disc, RT CL800 160/140mm rotors
Brake Levers	Shimano Ultegra hydraulic disc
Cassette	Shimano Ultegra, 11×34
Chain	Shimano CN-M8100
Crankset	Shimano Ultegra, 36/52 with Giant Power Pro power meter
Bottom Bracket	Shimano, press fit
Rims	New Giant SLR 0 40 Carbon Disc Wheel System with GIANT patented DBL (Dynamic Balanced Lacing) technology
Hubs	[F] Giant Low Friction Hub, CenterLock, 12mm thru-axle [R] Giant Low Friction Hub, 40t ratchet driver, CenterLock, 12mm thru-axle
Spokes	Giant Aero Carbon Spoke
Tyres	New CADEX Race GC Tubeless 700x28mm effecitve 170 TPI, Folding
Extras	Factory tubeless set up, out front computer mount
Max Tire Clearance	33mm

Highlights

Barcode : 4711291077676

Geometry

		XS	S	M	ML	L	XL
A	SEAT TUBE LENGTH	425	445	470	500	530	560
B	SEAT TUBE ANGLE	74.5	74	73.5	73	73	72.5
C	TOP TUBE LENGTH	520	535	550	565	580	600
D	HEAD TUBE LENGTH	120	130	145	165	185	200
E	HEAD TUBE ANGLE	71	72.3	73.5	73	73	72.5
F	FORK RAKE	45	45	45	45	45	45
G	TRAIL	72	64	59	59	59	59
H	WHEEL BASE	976	977	980	991	1,006	1,020
I	CHAIN STAY LENGTH	405	405	405	405	405	405
J	BOTTOM BRACKET DROP	72	69.5	69.5	67	67	67
K	STACK	517	528	545	562	581	596
L	REACH	376	383	388	393	402	412
M	STAND OVER HEIGHT	703	722	743	771	798	822
N	HANDLEBAR WIDTH	400	400	420	420	440	440
O	STEM LENGTH	80	90	100	110	110	120
P	CRANK LENGTH DEC	170	170	172.5	172.5	175	175
Q	WHEEL SIZE ALT	700C	700C	700C	700C	700C	700C
