Avail 2 (2021)
€859.00
Features:
Specifications
From epic solo adventures to group road rides, Avail is light, comfortable and engineered for female riders.
Key Performance Factors
Built for Endurance
Lightweight and balanced, the modern endurance geometry is designed for the female form, and delivers a smooth all-day ride experience.
Power Transfer
Sporting OverDrive and PowerCore technologies, this efficient frameset offers superior stiffness without compromising compliance.
Comfort
Liv’s 3F women’s-specific design, Advanced-Grade Composite fork and ALUXX tubing are ideal for venturing further and riding longer.
| Sizes | XXS, XS, M, L |
|---|---|
| Colours | Gloss Grayish Blue |
| Frame | ALUXX-Grade Aluminium. Compatible with fenders |
| Fork | Advanced-Grade Composite, OverDrive |
| Shock | N/A |
| Handlebar | Giant Connect |
| Stem | Giant Sport |
| Seatpost | Giant D-Fuse, alloy |
| Saddle | Liv Approach |
| Pedals | PEDALS NOT SUPPLIED |
| Shifters | Shimano Claris |
| Front Derailleur | Shimano Claris |
| Rear Derailleur | Shimano Claris |
| Brakes | Tektro TK-B177 |
| Brake Levers | Shimano Claris |
| Cassette | Shimano CS-HG50-8, 11×34 |
| Chain | KMC Z72 |
| Crankset | FSA Tempo, 34/50 |
| Bottom Bracket | cartridge |
| Rims | Giant S-R3 wheelset |
| Hubs | Giant S-R3 wheelset |
| Spokes | Giant S-R3 wheelset |
| Tyres | Giant S-R3 AC, 700x28c, wire bead |
Geometry
| XXS | XS | S | M | L | ||
|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 395 | 430 | 465 | 500 | 535 |
| B | SEAT TUBE ANGLE | 75 | 75 | 74.5 | 74 | 74 |
| C | TOP TUBE LENGTH | 500 | 515 | 525 | 540 | 555 |
| D | HEAD TUBE LENGTH | 120 | 135 | 150 | 170 | 190 |
| E | HEAD TUBE ANGLE | 70 | 70.5 | 72 | 72 | 72 |
| F | FORK RAKE | 45 | 45 | 45 | 45 | 45 |
| G | TRAIL | 76.2 | 73 | 63.5 | 63.5 | 63.5 |
| H | WHEEL BASE | 986 | 998 | 990 | 1000 | 1016 |
| I | CHAIN STAY LENGTH | 420 | 420 | 420 | 420 | 420 |
| J | BOTTOM BRACKET DROP | 70 | 70 | 70 | 70 | 70 |
| K | STACK | 514 | 530 | 550 | 569 | 588 |
| L | REACH | 362 | 372 | 372 | 377 | 386 |
| M | STAND OVER HEIGHT | 662 | 687 | 716 | 744 | 772 |
| N | HANDLERBAR WIDTH | 380 | 380 | 400 | 400 | 420 |
| O | STEM LENGTH | 70 | 70 | 80 | 90 | 90 |
| P | CRANK LENGTH DEC | 165 | 165 | 170 | 170 | 172.5 |
| Q | WHEEL SIZE ALT | 700C | 700C | 700C | 700C | 700C |
Technology and Features
