Additional information
| Colour | |
|---|---|
| Size |
Avail AR 1 (2021)
€2,069.00
Features:
Specifications
Follow your adventure off the paved path.
Key Performance Factors
Built for Endurance
Lightweight and balanced, the modern endurance geometry is designed specifically for women, and delivers a smooth all-day ride experience.
Power Transfer
Sporting OverDrive and PowerCore technologies, this efficient frameset offers superior stiffness without compromising compliance.
Comfort
Liv’s 3F women’s-specific design, Advanced-Grade Composite fork and ALUXX tubing are ideal for venturing further and riding longer.
| Sizes | XS, S, M, L |
|---|---|
| Colours | Gloss Rosewood / Eclipse |
| Frame | ALUXX-Grade Aluminium, disc. Compatible with fenders |
| Fork | Advanced-Grade Composite, OverDrive, disc |
| Shock | N/A |
| Handlebar | Giant Contact SL D-Fuse |
| Stem | Giant Contact |
| Seatpost | Giant D-Fuse, composite |
| Saddle | Liv Approach |
| Pedals | PEDALS NOT SUPPLIED |
| Shifters | Shimano 105 |
| Front Derailleur | Shimano 105 |
| Rear Derailleur | Shimano 105 GS |
| Brakes | Shimano 105 hydraulic |
| Brake Levers | Shimano 105 hydraulic |
| Cassette | Shimano 105, 11×34 |
| Chain | KMC X11EL-1 |
| Crankset | Shimano FC-RS510, 34/50 |
| Bottom Bracket | cartridge |
| Rims | Giant P-R2 Disc wheelset |
| Hubs | Giant P-R2 Disc wheelset |
| Spokes | Giant P-R2 Disc wheelset |
| Tyres | Giant Gavia Fondo 2, 700x32c, folding, tubeless (max tyre width possible: 40mm) |
| Extras | Tubeless ready |
Geometry
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 410 | 445 | 480 | 515 |
| B | SEAT TUBE ANGLE | 74.5 | 74.5 | 74 | 74 |
| C | TOP TUBE LENGTH | 515 | 525 | 540 | 555 |
| D | HEAD TUBE LENGTH | 118 | 138 | 158 | 178 |
| E | HEAD TUBE ANGLE | 70.5 | 71.5 | 72 | 72 |
| F | FORK RAKE | 53 | 53 | 53 | 53 |
| G | TRAIL | 69.5 | 62.9 | 59.6 | 59.6 |
| H | WHEEL BASE | 999 | 1001 | 1006 | 1022 |
| I | CHAIN STAY LENGTH | 422 | 422 | 422 | 422 |
| J | BOTTOM BRACKET DROP | 80 | 80 | 80 | 80 |
| K | STACK | 538 | 561 | 582 | 601 |
| L | REACH | 366 | 369 | 373 | 383 |
| M | STAND OVER HEIGHT | 681 | 709 | 736 | 766 |
| N | HANDLERBAR WIDTH | 380 | 400 | 400 | 420 |
| O | STEM LENGTH | 70 | 80 | 90 | 90 |
| P | CRANK LENGTH DEC | 165 | 170 | 170 | 175 |
| Q | WHEEL SIZE ALT | 700C | 700C | 700C | 700C |
Technology and Features
