From the stage race breakaway to the final criterium lap, the EnviLiv is made to be out front. We’ve designed our signature sprinter for optimized aerodynamic performance, greater stiffness-to-weight advantage, and maximum trophies.
EnviLiv Advanced 1
€2,048.20
From the stage race breakaway to the final criterium lap, the EnviLiv is made to be out front. We’ve designed our signature sprinter for optimized aerodynamic performance, greater stiffness-to-weight advantage, and maximum trophies.
Specifications
From the stage race breakaway to the final criterium lap, the EnviLiv is made to be out front. We’ve designed our signature sprinter for optimized aerodynamic performance, greater stiffness-to-weight advantage, and maximum trophies.
Key Performance Factors
Optimized Aerodynamics
In our pursuit of maximum power and efficiency, we analyze how the bike and rider experience airflow at every speed and direction, both on the computer and in the wind tunnel. The new EnviLiv features truncated ellipse airfoil tube shapes and the Liv Contact SL handlebar, with flattened tops and deeper drops, for reduced drag and added control, and better overall aero performance.
In our pursuit of maximum power and efficiency, we analyze how the bike and rider experience airflow at every speed and direction, both on the computer and in the wind tunnel. The new EnviLiv features truncated ellipse airfoil tube shapes and the Liv Contact SL handlebar, with flattened tops and deeper drops, for reduced drag and added control, and better overall aero performance.
Sprinting Efficiency
Aerodynamics are affected by many factors, two of them often seen as mutually exclusive: stiffness and weight. But the EnviLiv has found the sweet spot, with a new Advanced-grade composite frame and fork—resulting in 292 grams of weight savings over the previous generation.
Aerodynamics are affected by many factors, two of them often seen as mutually exclusive: stiffness and weight. But the EnviLiv has found the sweet spot, with a new Advanced-grade composite frame and fork—resulting in 292 grams of weight savings over the previous generation.
Seamless Integration
When every second matters, so does every detail. So we developed a way to route cables through the handlebar, stem, and frame, which improves aero performance, and also makes it easier to disassemble your bike for travel and maintenance. Two aerodynamic water bottle cages flawlessly integrate with the seat tube and down tube, further reducing drag.
When every second matters, so does every detail. So we developed a way to route cables through the handlebar, stem, and frame, which improves aero performance, and also makes it easier to disassemble your bike for travel and maintenance. Two aerodynamic water bottle cages flawlessly integrate with the seat tube and down tube, further reducing drag.
| Sizes | XXS, XS, S, M, L |
|---|---|
| Colours | Thundercloud/Chrome |
| Frame | Advanced-grade composite, 12x142mm thru-axle, disc |
| Fork | Advanced-grade composite, full-composite OverDrive Aero steerer, 12x100mm, disc |
| Shock | N/A |
| Handlebar | Liv Contact SL Aero, 31.8mm, XXS: 360mm, XS: 360mm, S: 380mm, M: 400mm, L: 420mm |
| Grips | Liv Stratus Elite 2.0 |
| Stem | Giant Contact SL Aero, XXS:80mm, XS:80mm, S:90mm, M:100mm, L:110mm |
| Seatpost | Giant Vector, composite, XXS: 350mm, XS: 350mm, S: 350mm, M: 350mm, L: 350mm |
| Saddle | Liv Alacra SL |
| Shifters | Shimano 105 Di2 |
| Front Derailleur | Shimano 105 Di2 FD-R7150 |
| Rear Derailleur | Shimano 105 Di2 RD-R7150 |
| Brakes | Shimano 105 Di2 hydraulic, Shimano RT-CL700 rotors, [F] 160mm, [R] 140mm |
| Brake Levers | Shimano 105 Di2 |
| Cassette | Shimano 105, 12-speed, 11×34 |
| Chain | KMC X12L-1 |
| Crankset | Shimano 105, 36/52, XXS: 160mm, XS: 165mm, S: 165mm, M: 170mm, L: 172.5mm |
| Bottom Bracket | Shimano, press fit |
| Rims | Giant SLR 2 50 Carbon Disc WheelSystem, [F] 50mm, [R] 50mm |
| Hubs | [F] Giant alloy, CenterLock, 12mm thru-axle, [R] Giant alloy, pawl driver(3-pawl 30T), CenterLock, 12mm thru-axle |
| Spokes | SAPIM Sprint |
| Tyres | Giant Gavia Course 0, 700x28c, folding, tubeless |
| Extras | computer mount, two bottle cages, tubeless prepared, 32mm max tire size |
| Max Tire Clearance | 32mm |
Highlights
Barcode : 4711291221185
Geometry
| XXS | XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 470 | 500 | 530 | ||||
| B | SEAT TUBE ANGLE | 75 | 74.5 | 74 | ||||
| C | TOP TUBE LENGTH | 508 | 524 | 540 | ||||
| D | HEAD TUBE LENGTH | 120 | 135 | 155 | ||||
| E | HEAD TUBE ANGLE | 71 | 72 | 72.5 | ||||
| F | FORK RAKE | 49 | 49 | 49 | ||||
| G | TRAIL | 66.3 | 59.9 | 56.8 | ||||
| H | WHEEL BASE | 973 | 977 | 984 | ||||
| I | CHAIN STAY LENGTH | 405 | 405 | 405 | ||||
| J | BOTTOM BRACKET DROP | 72 | 70 | 70 | ||||
| K | STACK | 517 | 532 | 553 | ||||
| L | REACH | 370 | 377 | 382 | ||||
| M | STAND OVER HEIGHT | 732 | 761 | 787 | ||||
| N | HANDLEBAR WIDTH | 360 | 380 | 400 | ||||
| O | STEM LENGTH | 80 | 90 | 100 | ||||
| P | CRANK LENGTH DEC | 165 | 165 | 170 | ||||
| Q | WHEEL SIZE ALT |
