Propel Advanced 1

€2,275.97

Maximize your watts during sprints, breakaways and solo attacks. This aero road machine is built to give you a real advantage against the wind. Because small gains lead to big wins.

Clear
SKU: N/A Categories: , , Tag:

Maximize your watts during sprints, breakaways and solo attacks. This aero road machine is built to give you a real advantage against the wind. Because small gains lead to big wins.

Additional information

Size

, , , , ,

Color

Specifications

Maximize your watts during sprints, breakaways and solo attacks. This aero road machine is built to give you a real advantage against the wind. Because small gains lead to big wins.

Key Performance Factors

Integrated aerodynamics
AeroSystem Shaping, a result of CFD analysis and dynamic wind-tunnel testing, optimizes aerodynamic performance at every yaw angle. The truncated ellipse airfoil tube shapes and all-new Contact SL Aero cockpit produce superior aero performance.
Easier adjustability
All-new cable routing through the stem and head tube makes it quicker and easier to adjust or change cockpit components and fine-tune performance and riding position.
Race-winning efficiency
Advanced-grade composite frame and hybrid alloy/composite fork deliver optimal stiffness and weight savings. The result is an even greater stiffness-to-weight advantage.
Sizes XS, S, M, M/L, L, XL
Colours Gloss Blue Dragonfly/Mercury
Frame Advanced-Grade Composite, 12x142mm thru-axle, disc
Fork Advanced-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
Shock N/A
Handlebar Giant Contact SL Aero
Grips Stratus Lite 2.0
Stem Giant Contact SL Aero
Seatpost Giant Vector, composite, -5/+15mm offset
Saddle Giant Fleet SL
Pedals PEDALS NOT SUPPLIED
Shifters Shimano 105 Di2 2×12
Front Derailleur Shimano 105 Di2
Rear Derailleur Shimano 105 Di2
Brakes Shimano 105 Di2 hydraulic, Shimano RT-70 rotors [F]160mm, [R]140mm
Brake Levers Shimano 105 Di2 hydraulic
Cassette Shimano 105, 12-speed, 11×34
Chain KMC X12L-1
Crankset Shimano 105, 36/52
Bottom Bracket Shimano, press fit
Rims Giant SLR 2 50 Carbon Disc WheelSystem, [F]50mm, [R]50mm
Hubs [F] Giant Low Friction Hub, CenterLock, [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
Spokes Sapim
Tyres Giant Gavia Course 1, tubeless,700x25c (28mm), folding
Extras Out front computer mount, water bottle cages, factory tubeless set up
Max Tire Clearance 32mm

Highlights

Barcode : 4711291092037

Geometry

XXS XS S M ML L XL
A SEAT TUBE LENGTH 465 500 520 545 575 595
B SEAT TUBE ANGLE 74.5 74 73.5 73 73 72.5
C TOP TUBE LENGTH 520 535 550 565 580 600
D HEAD TUBE LENGTH 120 130 145 165 185 200
E HEAD TUBE ANGLE 71 72.3 73 73 73 73
F FORK RAKE 45 45 45 45 45 45
G TRAIL 70.5 62.5 57.8 57.8 57.8 57.8
H WHEEL BASE 976 977 980 991 1,006 1,020
I CHAIN STAY LENGTH 405 405 405 405 405 405
J BOTTOM BRACKET DROP 72 70 70 67 67 67
K STACK 517 528 545 562 581 596
L REACH 376 383 388 393 402 412
M STAND OVER HEIGHT 722 753 770 794 821 834
N HANDLEBAR WIDTH 400 400 420 420 440 440
O STEM LENGTH 80 90 100 110 110 120
P CRANK LENGTH DEC 170 170 172.5 172.5 175 175
Q WHEEL SIZE ALT 700C 700C 700C 700C 700C 700C

Technology and Features

Advanced Composite Technology
AeroSystem Shaping Technology
OverDrive Aero
Tubeless System
