Revolt 2

€1,499.00

Ride roads, gravel or dirt with this versatile aluminum all-rounder. A composite fork gives it a smooth ride, and a flip chip lets you adjust wheelbase and tire clearance.

Additional information

Size	L, M, ML, S, XL
Color	Asphalt Green, Storm Cloud

Specifications

Ride roads, gravel or dirt with this versatile aluminum all-rounder. A composite fork gives it a smooth ride, and a flip chip lets you adjust wheelbase and tire clearance.

Key Performance Factors

Confident handling
Frame is designed with endurance positioning and shorter chainstays for precise handling, agility and control. A longer reach, shorter stem and lower bottom bracket drop improves stability on rugged terrain.

Tuned compliance
Dropped seatstays with thin tubing absorb road shocks and vibrations. The D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.

Adaptable to the terrain
A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling and acceleration, or long for improved stability at speed. The long setting allows for larger diameter tires up to 53mm. You can choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post.

Sizes	S, M, M/L, L, XL
Colours	Asphalt Green, Storm Cloud
Frame	ALUXX-grade aluminum, 12x142mm thru-axle, disc, flip chip dropout
Fork	Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Handlebar	Giant Contact XR Ergo-Control, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Grips	cork tape with gel
Stem	Giant Sport, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Seatpost	Giant D-Fuse, alloy, 14mm offset
Saddle	Giant Approach
Shifters	Shimano Sora, 2×9
Front Derailleur	Shimano Sora
Rear Derailleur	Shimano Sora, long cage
Brakes	Tektro MD-C550 mechanical, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers	Shimano Sora
Cassette	Shimano HG400, 11×34
Chain	KMC X9 with Missing Link
Crankset	FSA Vero Pro, 32/48 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket	cartridge
Rims	Giant S-X2 Disc wheelset, alloy
Hubs	Giant alloy, 12mm thru-axle
Spokes	stainless
Tyres	Giant CrossCut AT 2, 700x38c, tubeless
Extras	tubeless prepared, 53mm max tire size in “long” flip chip position, 45mm max tire size in “short” flip chip position
Max Tire Clearance	53mm

Geometry

		S	M	ML	L	XL
A	SEAT TUBE LENGTH	450	470	490	510	530
B	SEAT TUBE ANGLE	73.5	73.5	73	73	73
C	TOP TUBE LENGTH	550	560	575	585	600
D	HEAD TUBE LENGTH	135	150	165	180	195
E	HEAD TUBE ANGLE	71	71.5	72	72	72
F	FORK RAKE	50	50	50	50	50
G	TRAIL	72	68	65	65	65
H	WHEEL BASE	1,025	1,030	1,035	1,045	1,061
I	CHAIN STAY LENGTH	430	430	430	430	430
J	BOTTOM BRACKET DROP	80	80	80	80	80
K	STACK	570	586	602	616	630
L	REACH	381	387	391	397	407
M	STAND OVER HEIGHT	734	752	769	786	801
N	HANDLEBAR WIDTH	420	440	440	460	460
O	STEM LENGTH	60	70	80	80	90
P	CRANK LENGTH DEC	170	172.5	172.5	175	175
Q	WHEEL SIZE ALT	700x 42C \|	700x 42C \|	700x 42C \|	700x 42C \|	700x 42C \|
