CUBE STEREO HYBRID ONE77 HPC AT 800 CARBON/GOLD XL
The Stereo Hybrid ONE77 HPC AT is built with big mountains in mind. To that end, we fitted Fox’s Float 38 Factory fork and Float X2 Factory shock – because when you’re making full use of 170mm of travel, you need to know you’re in good hands. Shimano’s XT Di2 1×12 gears select with uncanny electronic precision, getting your power to the trail with help from Bosch’s CX drive, the 800Wh PowerTube battery, a Kiox 400C top tube-mounted display and an ACID carbon crank. We added a remote dropper seatpost for extra confidence and manoeuvrability on tough trails, while Shimano XT hydraulic disc brakes with ABS Pro ensure you can safely keep your speed in check. And Newmen Beskar 30 wheels – in mullet configuration – with Schwalbe 2.5in Magic Mary and Albert tyres – keep you rolling, whatever obstacles lie in your path.
Frame description
The Stereo Hybrid ONE77 HPC frame – with 170mm travel front and rear and a mullet wheel setup with 29in front and 27.5in rear – is all you need for big days out on big mountain trails. But, as with all CUBE designs, the devil is in the detail. So, for example, we added Integrated Cable Routing for super-clean looks, and then threw in an angle-adjustable headset so that you can tweak the handling to your taste. The 800Wh PowerTube battery sits unobtrusively in the carbon down tube, just above the Bosch CX drive. A UDH dropout on the aluminium rear triangle is tough and future-proof, and we also added a Direct Mount chain guide to keep you driving forwards even when the going gets rough.
STEREO HYBRID ONE77 HPC
The Stereo Hybrid ONE77 HPC AT is built with big mountains in mind. To that end, we fitted Fox’s Float 38 Factory fork and Float X2 Factory shock – because when you’re making full use of 170mm of travel, you need to know you’re in good hands. Shimano’s XT Di2 1×12 gears select with uncanny electronic precision, getting your power to the trail with help from Bosch’s CX drive, the 800Wh PowerTube battery, a Kiox 400C top tube-mounted display and an ACID carbon crank. We added a remote dropper seatpost for extra confidence and manoeuvrability on tough trails, while Shimano XT hydraulic disc brakes with ABS Pro ensure you can safely keep your speed in check. And Newmen Beskar 30 wheels – in mullet configuration – with Schwalbe 2.5in Magic Mary and Albert tyres – keep you rolling, whatever obstacles lie in your path.
Frame description
The Stereo Hybrid ONE77 HPC frame – with 170mm travel front and rear and a mullet wheel setup with 29in front and 27.5in rear – is all you need for big days out on big mountain trails. But, as with all CUBE designs, the devil is in the detail. So, for example, we added Integrated Cable Routing for super-clean looks, and then threw in an angle-adjustable headset so that you can tweak the handling to your taste. The 800Wh PowerTube battery sits unobtrusively in the carbon down tube, just above the Bosch CX drive. A UDH dropout on the aluminium rear triangle is tough and future-proof, and we also added a Direct Mount chain guide to keep you driving forwards even when the going gets rough.
| Fork | |
|---|---|
| Fork Brand | FOX |
| Fork Model | 38 Float Factory GRIPX2, Tapered, 15x110mm, E-Bike Optimized, 170mm |
| Fork Suspension | 1 |
| Fork Brand Description | Fox |
| Stem | |
| Stem Brand | CUBE |
| Stem Model | Performance Stem E-MTB 35, FPI-Link |
| Stem Brand Description | Cube |
| Chain | |
| Chain Brand | SHIMANO |
| Chain Model | XT CN-M8100 |
| Chain Brand Description | Shimano |
| Frame | |
| Frametype | UNI |
| Framematerial | CARBON |
| Framesize Supplier | L |
| Frametype Description | Unisex |
| Framematerial Description | Carbon |
| Gears | |
| Gear Type | DERAILLEUR |
| Gear Brand | SHIMANO |
| Gear Model | XT Di2 |
| Number Of Gears | 12 |
| Gear Brand Description | Shimano |
| Gear Type Description | Derailleur |
| Pedals | |
| Pedals Brand | ACID |
| Pedals Model | PP MTB |
| Pedals Brand Description | Acid |
| Saddle | |
| Saddle Brand | ACID |
| Saddle Model | Venec EMTB Trail 140 |
| Saddle Brand Description | Acid |
| Wheels | |
| Wheels Brand | NEWMEN |
| Wheels Model | Beskar 30 base/strong, 28/32 Spokes, 15x110mm/12x148mm, Tubeless Ready |
| Wheels Brand Description | Newmen |
| Headset | |
| Headset Brand | ACROS |
| Headset Model | AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
| Headset Brand Description | Acros |
| Cassette | |
| Cassette Brand | SHIMANO |
| Cassette Model | XT CS-M8100, 10-51T |
| Cassette Brand Description | Shimano |
| Crankset | |
| Crankset Brand | ACID |
| Crankset Model | MTB Hybrid Carbon, 36T |
| Crankset Brand Description | Acid |
| Seatpost | |
| Seatpost Brand | FOX |
| Seatpost Model | Transfer Factory 31.6mm, Kashima Coated |
| Seatpost Brand Description | Fox |
| Shifters | |
| Shifters Brand | SHIMANO |
| Shifters Model | XT Di2 SW-M8250-IR, Direct Attach |
| Shifters Brand Description | Shimano |
| Handlebar | |
| Handlebar Brand | RACEFACE |
| Handlebar Model | ERA 35 |
| Handlebar Brand Description | RaceFace |
| Front Brake | |
| Front Brake Type | SH |
| Front Brake Brand | SHIMANO |
| Front Brake Model | XT BR-M8220, Hydr. Disc Brake w/ Front ABS (203/203) |
| Front Brake Brand Description | Shimano |
| Front Brake Type Description | Disc brake with hydraulic actuation |
| Seatpost Clamp | |
| Seatpost Clamp Brand | CUBE |
| Seatpost Clamp Model | Semi-Integrated |
| Seatpost Clamp Brand Description | Cube |
| Derailleur Rear | |
| Derailleur Rear Brand | SHIMANO |
| Derailleur Rear Model | XT Di2 RD-M8260-SGS, 12-Speed, Electronic Shifting System |
| Derailleur Rear Brand Description | Shimano |
| Bartape Or Grips | |
| Bartape Or Grips Brand | ACID |
| Bartape Or Grips Model | Disrupt, Soft Compound |
| Bartape Or Grips Brand Description | Acid |
| Primary Rear Brake | |
| Primary Rear Brake Type | SH |
| Primary Rear Brake Brand | SHIMANO |
| Primary Rear Brake Model | XT BR-M8220, Hydr. Disc Brake w/ Front ABS (203/203) |
| Primary Rear Brake Brand Description | Shimano |
| Primary Rear Brake Type Description | Disc brake with hydraulic actuation |
| Physical Specifications | |
| Size | L |
| Colour | CARBON/GOLD |
| Net Weight | 24.7 |
| Gross Weight | 29.68 |
| Weight Capacity | 160 |
| Primary Basecolour | BLACK |
| Secondary Basecolour | GOLD |
| Primary Basecolour Description | Black |
| Secondary Basecolour Description | Gold |
