Defy Advanced E+ Elite 1

€9,199.00

With its smooth-riding composite frame, lightweight battery, and new SyncDrive Move Plus integrated rear hub motor, the Defy Advanced E+ is the ideal choice for performance-minded road riders who want to tackle steep hills, maintain higher speeds, and experience road riding with no limitations.

Category: Bikes, E Bikes, E Road Tag: 3247, Apply Now, Giant

View

Size L, M, ML, S

Color Raw Carbon

Specifications

Key Performance Factors

SEAMLESS POWER
The SyncDrive Move Plus motor is integrated into the rear hub and delivers 30Nm of power (equivalent to 75Nm with a mid-drive motor) directly to the rear wheel. Weighing just 1.7kg, it’s specially tuned for the pedaling pattern of performance road riding, with minimal energy loss and more torque at higher speeds. The result is a natural feel when accelerating or maintaining steady power at speed, and no motor drag while freewheeling or coasting.

SYSTEM INTEGRATION
The down tube integrated EnergyPak 400 battery system weighs just 2.3kg and is purpose-built for the specific needs of E-bikes. A top tube mounted RideControl Go button makes it quick and easy to turn the E-bike on or off and change power modes. Smart Assist technology uses three sensors to precisely measure the power being applied to the pedals and produce just the right amount of support for a smooth, natural ride experience. All models feature SRAM wireless electronic shifters and an integrated taillight.

PURE ROAD PERFORMANCE
A lightweight composite frameset and high-performance components including a D-Fuse seatpost and handlebars for compliance, integrated WheelSystems with tubeless tires, and a wireless electronic drivetrain all add up to a smooth, efficient ride quality that mirrors the award-winning performance of the Defy endurance road bike range.

Motor	SyncDriveMove Plus Hub drive 75Nm max
Controller	Mode support switch from SRAM Blips
Display	Giant RideControl GO, frame-integrated LED console Optional wireless ANT+ display
Battery	EnergyPak Smart 400Wh by Panasonic, Aluminium casing with highest safety standard (UL2271, EN50604), CO2 Neutral production, 2300 charging cycles. EnergyPak Plus 200 range extender compatible
Charger	Giant EnergyPak 4A smart charger, 60% in 1:45
Connectivity	Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
Sizes	S, M, ML, L
Colours	Gloss Raw carbon / Black
Frame	Advanced-grade composite,12×145 thru-axle
Fork	Advanced SL-Grade Composite, Full-Composite OverDrive Aero Steerer, 12x100mm thru-axle, Disc
Shock	–
Handlebar	Giant Contact SLR D-Fuse 31.8 carbon
Stem	Contact SLR Aerolight 31.8 carbon
Seatpost	Giant D-Fuse SL, Composite, 16mm offset
Saddle	Giant Fleet SL
Pedals	PEDALS NOT SUPPLIED
Shifters	Sram Force eTap AXS 2×12
Front Derailleur	Sram Force AXS
Rear Derailleur	Sram Force AXS
Brakes	Sram Force AXS HRD, Centerline 160mm center-lock [F] 160mm 6-bols [R]
Brake Levers	Sram Force AXS HRD
Cassette	SRAM Force XG-1270 10x33T 12-speed
Chain	Sram Force 12-speed
Crankset	Sram Force X-SYNC 33/46T BCD107 chain ring Praxis E Crank Carbon ISIS
Bottom Bracket	Giant E+ System BBSS
Rims	Giant SLR 1 E+ 36 Carbon Disc Wheel System, Hookless, Tubeless Ready, 12mm thru-axle, w/ Sapim spoke E-Light [R] CX-Ray [F], e-bike optimised
Spokes	Sapim spoke E-Light [R] CX-Ray [F], e-bike optimised
Tyres	Cadex Classic 75PSI 700x32C 170TPI Tubeless Foldable
Lighting	Seatpost clamp integrated tail light

Highlights

Barcode : 4712878896611

Geometry

		S	M	ML	L
A	SEAT TUBE LENGTH	445	480	515	535
B	SEAT TUBE ANGLE	74	73.5	73	73
C	TOP TUBE LENGTH	530	545	560	575
D	HEAD TUBE LENGTH	130	145	167	187
E	HEAD TUBE ANGLE	71.5	72.5	72.5	72.5
F	FORK RAKE	50	50	50	50
G	TRAIL	65.1	58.6	58.6	58.6
H	WHEEL BASE	994.3	995.2	1,007.5	1,022.7
I	CHAIN STAY LENGTH	420	420	420	420
J	BOTTOM BRACKET DROP	80	80	75	75
K	STACK	542.2	560.2	576.1	595.2
L	REACH	374.3	378.9	383.6	392.8
M	STAND OVER HEIGHT	716	745.5	779	799
N	HANDLEBAR WIDTH	400	420	420	440
O	STEM LENGTH	90	100	110	110
P	CRANK LENGTH DEC	170	172.5	172.5	175
Q	WHEEL SIZE ALT	700C	700C	700C	700C
